Manufacturer: Goodyear
Brand name: Goodyear
Product weight: 7.48 kilograms
Package size: 24 x 24 x 24 cm
Model: 2B8-155
2B8-155 Goodyear Technical parameters
| Number of top plate holes / studs: | 3 | |
| Top plate diameter: | 6.4 inch | 162.56 mm |
| Top plate C to C diameter: | 3.5 inch | 88.9 mm |
| Base plate hole bolt Qyt: | | |
| Base plate diameter: | 6.4 inch | 162.56 mm |
| Base plate C to C diameter: | 3.5 inch | 88.9 mm |
| Base plate part number: | | |
| Base plate alignment: parallel | | |
| Bumper: no | | |
| bracket: | | |
| Minimum height: 3.2 | 3.2 inch | 81.28 mm |
| Maximum height: 10.8 | 10.8 inch | 274.32 mm |
Nut / Blind Nut
Top Cover Plate Screw (Nut) Tooth : 2 pcs X 3/8-16UNC
Screw Center Distance of Top Cover Plate : 89 mm
Bottom Cover Plate Screw (Nut) Tooth : 2 pcs X 3/8-16UNC
Screw Center Distance of Bottom Cover Plate : 89 mm
Gas Hole / Air inlet / Air Fitting
Gas Hole / Air inlet : 1/4-18NPTF
Screw Center Distance Between Gas Hole and Nut : 44.5 mm
Cover Plate
Top Cover Plate Diameter: 160 mm
Bottom Cover Plate Diameter: 160 mm
Rubber Bellows
Rubber Bellows MAX Diameter: 251 mm
Rubber Bellows Natural Diameter : 224 mm
The Working Stroke : MIN 75 mm to MAX 260 mm
Maximum Height : 274 mm
Minimum Height :95mm
Stroke Height : 179mm
Bumper block / Buffer block
Without Bumper Block
Girdle Hoop / Girdle Ring
With Girdle Hoop :One Pieces of Girdle Hoop
Goodyear 2B8-155 Suspension Air Springs Cross others OEM
| OEM Reference | OEM Reference |
| Granning: 1371 | Taurus: AS218-6910 |
| Triangle Spring: 4320 | Dallas Spring: AS6910 |
| Firestone: 6910 | Sirco: AS-6910 |
| Conti Tech: 64267 | Midland/Haldex: CS209200 |
| R & S Truck: 1027405 | Euclid/Meritor Aftermarket: E-FS6910 |
| Ridewell: 1003586910C | Conti Tech: FD200-19320 |
| Batco: 10-96910 | Euclid/Meritor Aftermarket: FS6910 |
| Reyco: 23704-01 | BWP: M-3501 |
| Hendrickson: 45843-3 | HD America: PMABG-6910B |
| Navistar/IHC: 554783C1 | Ridewell: S4512C |
| UCF/Impex: AB-2B9-200 | Leland: SC201 |
| Automann: ABSP2B12R-6910 | Leland: SC2011 |
| Watson & Chalin: AS0001 | |
Details pictures of Goodyear Air Spring Original 2b9-200:
Bulk product pictures of Goodyear Air Spring Original 2b9-200:
| 57992255000000 | 20035816 | Y | 2B8-550 | 2B8-550 |
| 2B8-550 | 20095586 | N | 2B8-550 Bellows Air Spring | 2B8-550 Bellows Air Spring |
| 57992255000019 | 20054210 | Y | ENIDINE YI-2B8-550 | ENIDINE YI-2B8-550 |
| 57992255000042 | 20561425 | Y | 2B8-550 INTERNATIONAL 3882214C1 | 2B8-550 INTERNATIONAL 3882214C1 |
| 2B8-552 | 20095591 | N | 2B8-552 | 2B8-552 |
| 57992255200019 | 20095592 | Y | ENIDINE YI-2B8-552 | ENIDINE YI-2B8-552 |
| 2B8-553 | 20095593 | N | 2B8-553 | 2B8-553 |
| 57992255300004 | 20409616 | Y | 2B8-553 TRUCK AIR SPRING | 2B8-553 TRUCK AIR SPRING |
| 57992255300019 | 20095594 | Y | ENIDINE YI-2B8-553 | ENIDINE YI-2B8-553 |
| 57992255300021 | 20119143 | Y | 58205 2B8-553 | 58205 2B8-553 |
| 57992255400000 | 20095595 | Y | 2B8-554 | 2B8-554 |
| 57992255400019 | 20095596 | Y | ENIDINE YI-2B8-554 | ENIDINE YI-2B8-554 |
| 57992255500038 | 20439367 | Y | 2B8-555 HEND - FOR COSTING | 2B8-555 HEND - FOR COSTING |
| 57992255700090 | 20810736 | Y | C 2B6-535 | C 2B6-535 |
| 57992255700094 | 20811198 | Y | C 2B6-535 | C 2B6-535 |
| 57992255800090 | 20811609 | Y | C 2B7-540 | C 2B7-540 |
| 57992255800094 | 20810737 | Y | C 2B7-540 | C 2B7-540 |
| 57992255900090 | 20810738 | Y | C 2B7-842 | C 2B7-842 |
| 57992256000090 | 20811615 | Y | C 2B7-541 | C 2B7-541 |
| 57992256200094 | 20811617 | Y | C 2B8-550 | C 2B8-550 |
| 57992274000000 | 20095599 | Y | 2B7-740 | 2B7-740 |
| 57992283000019 | 20106784 | Y | ENIDINE YI-2B6-830 | ENIDINE YI-2B6-830 |
| 2B6-833 | 20095600 | N | 2B6-833 | 2B6-833 |
| 57992283300019 | 20095601 | Y | ENIDINE YI-2B6-833 METRIC | ENIDINE YI-2B6-833 METRIC |
| 57992283500019 | 20257581 | Y | ENIDINE YI-2B6-835 | ENIDINE YI-2B6-835 |
| 57992283900000 | 20054211 | Y | 2B6-839 M | 2B6-839 M |
| 2B7-840 | 20316800 | N | 2B7-840 | 2B7-840 |
| 57992284000019 | 20117075 | Y | ENIDINE YI-2B7-840 | ENIDINE YI-2B7-840 |
| 57992284100090 | 20811618 | Y | C 2B6-839 M | C 2B6-839 M |
| 57992284200000 | 20069561 | Y | KUHN 2B7-842 M | KUHN 2B7-842 M |
| 2B7-843 | 20588389 | N | 2B7-843 M | 2B7-843 M |
| 2B8-850 | 20095602 | N | 2B8-850 METRIC | 2B8-850 METRIC |
| 57992285000019 | 20095603 | Y | ENIDINE YI-2B8-850 | ENIDINE YI-2B8-850 |
| 57992285300000 | 20221915 | Y | KUHN 2B8-853 (METRIC) | KUHN 2B8-853 (METRIC) |
| 2B8-854 | 20054212 | N | 2B8-854 M | 2B8-854 M |
| 57992285600090 | 20806001 | Y | C 2B8-854 | C 2B8-854 |
| 57992351100000 | 20109236 | Y | 2B6-REG AIR LIFT G5814 FLEXMEMBER | 2B6-REG AIR LIFT G5814 FLEXMEMBER |
| 57992351500011 | 20295315 | Y | 2B6-EXT ARNOTT FLEXMEMBER | 2B6-EXT ARNOTT FLEXMEMBER |
| 57992351600000 | 20095608 | Y | 2B6 EXT SLEEVE G5813 AIR LIFT | 2B6 EXT SLEEVE G5813 AIR LIFT |
| 57992351800000 | 20177365 | Y | 2B6-EXT AIR LIFT 5817 FLEXMEMBER | 2B6-EXT AIR LIFT 5817 FLEXMEMBER |
| 57992352000000 | 20109238 | Y | 2B7 AIR LIFT MSB FLEXMEMBER | 2B7 AIR LIFT MSB FLEXMEMBER |
| 57992352200000 | 20168398 | Y | 2B7-REG AIR LIFT 5815 FLEXMEMBER | 2B7-REG AIR LIFT 5815 FLEXMEMBER |
| 57992352300000 | 20177366 | Y | 2B7-REG AIR LIFT 5818 FLEXMEMBER | 2B7-REG AIR LIFT 5818 FLEXMEMBER |
| 57992353200000 | 20439364 | Y | 2B8 SLD GRDL RNG - FOR COSTING | 2B8 SLD GRDL RNG - FOR COSTING |
| 57999571600000 | 20054214 | Y | KUHN TOOLING | KUHN TOOLING |
